Brand | CP PLUS |
---|---|
Manufacturer | CP PLUS, ADITYA Infotech Ltd, |
Country of Origin | India |
Number of Channels | 16 |
Memory Storage Capacity | 6 TB |
Hard Disk Size | 6 TB |
Number of USB Ports | 2 |
Connectivity Technology | VGA, USB, HDMI |
Compatible Device | Camera |
ProcessorEmbedded processor Operating SystemEmbedded LINUX IP Camera Input16+2, each channel up to 6MP Two-way TalkReuse audio in/out, RCA User InterfaceGUI Video Output1 HDMI, 1 VGA Video Resolution1080N, 720P, 960H, D1, HD1, BCIF, CIF, QCIF Video RecordingMain Stream: the 1st channel 1080N/720P (1 fps–25/30 fps), others 1080N/720P (1 fps–15 fps); 960H/D1/HD1/BCIF/CIF/QCIF (1 fps–25/30 fps) Sub stream: CIF/QCIF (1 fps–7 fps) Video Display Split1/4/8/9/16 Video Channel16 channel, BNC Audio Output1 channel, RCA Audio Channel1 channel, RCA Motion DetectionMD Zones: 396 (22 × 18) Video LossSupports Smart PhoneiPhone, iPad, Android Phone Hard Disk1 SATA port, up to 6TB Trigger EventsRecording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips Recording ModeManual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop Search ModeTime /Date, Alarm, MD and Exact Search (accurate to second) Backup ModeUSB Device/Network PlaybackPlay, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file,Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup, selection, Digital zoom Max User Account128 users Record Interval1~60 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec EthernetRJ-45 port (100M) Interface Ports1 HDMI, 1 VGA, 2 USB2.0 ProtocolsHTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter ,DDNS, FTP, Alarm Server, P2P, IP Search, ONVIF 16.12, CGI Conformant Power SupplyDC12V/2A Power Consumption<10W(without HDD) Working Temp-10°C ~ +45°C (+14°F ~ +113°F), 10 ~ 90% RH Dimension260mm x 236mm x 48mm Weight0.89kg (without HDD)
